Azure Stack

How to shutdown and start an Azure Stack system.

How to shutdown and start an Azure Stack system.

I've been intending for a couple of months on how to shut down an Azure Stack integrated system 'the right way'.  Why?  Because I had to turn off an instance a couple of months ago due to the location hosting the appliance having planned utility maintenance (it hosts pilot/demo kit only so no need for generators), and didn't want any issues with tenant workloads or S2D. Anyway, I don't particularly need to detail the process now as Microsoft have recently updated their documentation detailing the process (get it here).

Azure Stack TP3 Stability (Reboot the XRP VM)


If you have been deploying and using Azure Stack TP3, you may have noticed after a few days the portal starts behaving slower and in my experience closer to a week it stops working altogether.  This will vary depending on what you're doing and your hardware.  Looking at the VM guests, you will notice that the XRP VM is consuming all its memory.  While you could give the machine more memory, this does mess with the expected infrastructure sizing and eventually, it will consume whatever memory you give it. This will hopefully be addressed soon. However, a simple workaround is to reboot the XRP VM. Why do anything manually when you can script it?  This very simple script creates a scheduled task that will run on Sunday night at 1 am.  The task will stop and start the XRP VM and then trigger the existing ColdStartMachine task that makes sure all the Azure Stack services are running.

[powershell] #run on host server as the AzureStackAdmin user $AzureStackAdminPAssword = 'YOURPASSWORD'

$Action = New-ScheduledTaskAction -Execute 'Powershell.exe' -argument '-command "Get-VM MAS-Xrp01 | Stop-VM -force;Get-VM MAS-Xrp01 | start-vm;sleep 180;Stop-ScheduledTask ColdStartMachine ;start-scheduledtask ColdStartMachine"' $trigger = New-ScheduledTaskTrigger -Weekly -DaysOfWeek Sunday -at 1am Register-ScheduledTask -Action $Action -Trigger $trigger -taskname "XRPReboot" -Description "Restart XRP VM weekly" -RunLevel Highest -User "$env:USERDOMAIN\$env:USERNAME" -Password $AzureStackAdminPAssword [/powershell]



Publishing Microsoft Azure Stack TP3 on the Internet via NAT


As you may know? Azure Stack TP3 is here. This blog will outline how to publish your azure stack instance on the internet using NAT rules to redirect your external IP Address to the internal, external IPs. Our group published another article on how to do this for TP2 and this is the updated version for TP3. Starting Point This article assumes you have a host ready for installation with the TP3 VHDx loaded onto your host and you are familiar with the Azure Stack installation Process. The code in this article is extracted from a larger process but should be enough to get you through the process end to end. Azure Stack Installation First things first, I like to install a few other tools to help me edit code and access the portal, this is not required.

[powershell] iwr -UseBasicParsing | iex choco install notepadplusplus -y choco install googlechrome -y --ignore-checksums choco install visualstudiocode -y choco install beyondcompare -y choco install baretail -y choco install powergui -y --ignore-checksums [/powershell]

Next, you want to open up this file C:\clouddeployment\setup\DeploySingleNode.ps1

Editing these values allow you to create different internal naming and external space.  As you can see the ExternalDomainFQDN is made up of the region and external suffix.

This is a lot easier now the domain parameters are used from the same place, no need to hunt down domain names in files.

[powershell] $AdminPassword = 'SuperSecret!'|ConvertTo-SecureString -AsPlainText -force $AadAdminPass= 'SuperSecret!'|ConvertTo-SecureString -AsPlainText -Force $aadCred = New-Object PSCredential('',$AadAdminPass)

. c:\clouddeployment\setup\InstallAzureStackPOC.ps1 -AzureEnvironment "AzureCloud" ` -AdminPassword $AdminPassword ` -PublicVLanId 97 ` -NATIPv4Subnet '' ` -NATIPv4Address '' ` -NATIPv4DefaultGateway '' ` -InfraAzureDirectoryTenantAdminCredential $aadCred ` -InfraAzureDirectoryTenantName '' ` -EnvironmentDNS '' ` [/powershell]

Remember to only have one nic enabled. We also have slightly less than the minimum space required for the OS disk and simply edit the XML file here C:\CloudDeployment\Configuration\Roles\Infrastructure\BareMetal\OneNodeRole.xml and change the value of this node Role.PrivateInfo.ValidationRequirements.MinimumSizeOfSystemDiskGB. The rest is over to TP3 installation, so far our experience of TP3 is much more stable to install, just the occasional rerun using

[powershell]InstallAzureStackPOC.ps1 -rerun[/powershell]

Once the installation completes obviously check you can access the portal.  I use chrome as it asks a lot less questions to confirm the portal is running.  We use a JSON file defined by a larger automation script to deploy these NAT rules.   Here I will simply share a portion of the resulting JSON file that is saved to C:\CloudDeployment\Setup\StackRecord.json.

[xml] { "Region": "SV5", "ExternalDomain": "", "nr_Table": ",443:", "nr_Queue": ",443:", "nr_blob": ",443:", "nr_adfs": ",443:", "nr_graph": ",443:", "nr_api": "", "nr_portal": ",30015,13001,13010,13021,13020,443,13003,13026,12648,12650,12499,12495,12647,12646,12649:", "nr_publicapi": "", "nr_publicportal": ",30015,13001,13010,13021,13020,443,13003,12495,12649:", "nr_crl": "", "nr_extensions": ",12490,12491,12498:", }


This is used by this script also saved to the setup folder

[powershell] param ( $StackBuildJSONPath='C:\CloudDeployment\Setup\StackRecord.json' )

$server = 'mas-bgpnat01' $StackBuild = Get-Content $StackBuildJSONPath | ConvertFrom-Json

[scriptblock]$ScriptBlockAddExternal = { param($ExIp) $NatSetup=Get-NetNat Write-Verbose 'Adding External Address $ExIp' Add-NetNatExternalAddress -NatName $NatSetup.Name -IPAddress $ExIp -PortStart 80 -PortEnd 63356 }

[scriptblock]$ScriptblockAddPorts = { param( $ExIp, $natport, $InternalIp ) Write-Verbose "Adding NAT Mapping $($ExIp):$($natport)->$($InternalIp):$($natport)" Add-NetNatStaticMapping -NatName $NatSetup.Name -Protocol TCP -ExternalIPAddress $ExIp -InternalIPAddress $InternalIp -ExternalPort $natport -InternalPort $NatPort }

$NatRules = @() $NatRuleNames = ($StackBuild | get-member | ? {$ -like "nr_*"}).name foreach ($NATName in $NatRuleNames ) { $NatRule = '' | select name, Internal, External, Ports $ = $NATName.Replace('nr_','') $rules = $StackBuild.($NATName).split(':') $natrule.Internal = $rules[0] $natrule.External = $rules[2] $natrule.Ports = $rules[1] $NatRules += $NatRule }

$session = New-PSSession -ComputerName $server

foreach ($NatRule in $NatRules) { Invoke-Command -Session $session -ScriptBlock $ScriptBlockAddExternal -ArgumentList $NatRule.External $NatPorts = $NatRule.Ports.Split(',').trim() foreach ($NatPort in $NatPorts) { Invoke-Command -Session $session -ScriptBlock $ScriptblockAddPorts -ArgumentList $NatRule.External,$NatPort,$NatRule.Internal } }

remove-pssession $session [/powershell]

Next, you need to publish your DNS Records. You can do this by hand if you know your NAT Mappings and as a reference, you can open up the DNS server on the MAS-DC01.

However, here are some scripts I have created to help automate this process. I do run this from another machine but have edited it to run in the context of the AzureStack Host. First, we need a couple of reference files.

DNSMappings C:\clouddeployment\setup\DNSMapping.json

[xml] [ { "Name": "nr_Table", "A": "*", "Subdomain": "table", "Zone": "RegionZone.DomainZone" }, { "Name": "nr_Queue", "A": "*", "Subdomain": "queue", "Zone": "RegionZone.DomainZone" }, { "Name": "nr_blob", "A": "*", "Subdomain": "blob", "Zone": "RegionZone.DomainZone" }, { "Name": "nr_adfs", "A": "adfs", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_graph", "A": "graph", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_api", "A": "api", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_portal", "A": "portal", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_publicapi", "A": "publicapi", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_publicportal", "A": "publicportal", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_crl", "A": "crl", "Subdomain": "RegionZone", "Zone": "DomainZone" }, { "Name": "nr_extensions", "A": "*", "Subdomain": "vault", "Zone": "RegionZone.DomainZone" }, { "Name": "nr_extensions", "A": "*", "Subdomain": "vaultcore", "Zone": "RegionZone.DomainZone" } ]


ExternalMapping C:\clouddeployment\setup\ExternalMapping.json This is a smaller section the contain on the NAT mappings reference in this example.

[xml] [ { "External": "3x.7x.2xx.133", "Internal": "" }, { "External": "3x.7x.2xx.134", "Internal": "" }, { "External": "3x.7x.2xx.135", "Internal": "" }, { "External": "3x.7x.2xx.136", "Internal": "" }, { "External": "3x.7x.2xx.137", "Internal": "" }, { "External": "3x.7x.2xx.138", "Internal": "" }, { "External": "3x.7x.2xx.139", "Internal": "" }, { "External": "3x.7x.2xx.140", "Internal": "" }, { "External": "3x.7x.2xx.141", "Internal": "" }, { "External": "3x.7x.2xx.142", "Internal": "" }, { "External": "3x.7x.2xx.143", "Internal": "" } ] [/xml]

Bringing it altogether with this script

[powershell] Param ( $StackJSONPath = 'c:\clouddeployment\setup\StackRecord.json' )

$stackRecord = Get-Content $StackJSONPath | ConvertFrom-Json $DNSMappings = get-content c:\clouddeployment\setup\DNSMapping.json | ConvertFrom-Json $ExternalMapping = get-content c:\clouddeployment\setup\ExternalMapping.json | ConvertFrom-Json

$DNSRecords = @() foreach ($DNSMapping in $DNSMappings) { $DNSRecord = '' | select Name, A, IP, Subdomain, Domain $DNS = $stackRecord.($DNSMapping.Name).split(':') $DNSRecord.IP = ($ExternalMapping | ? {$_.Internal -eq $DNS[2]}).external $DNSRecord.Name = $DNSMapping $DNSRecord.A = $DNSMapping.A $DNSRecord.Subdomain = $DNSMapping.Subdomain.Replace("RegionZone",$stackRecord.Region.ToLower()).Replace("DomainZone",$stackRecord.ExternalDomain.ToLower()) $DNSRecord.Domain = $"RegionZone",$stackRecord.Region.ToLower()).Replace("DomainZone",$stackRecord.ExternalDomain.ToLower()) $DNSRecords += $DNSRecord } #here you can use this array to do what you need, 2 examples follow

#CSV host file for import $DNSRecords | select a,IP, Subdomain, domain | ConvertTo-CSV -NoTypeInformation | Set-Content c:\clouddeployment\setup\DNSRecords.csv

$SubDomains = $DNSRecords | group subdomain foreach ($SubDomain in ($SubDomains | Where {$ -ne ''}) ) { Write-Output ("Records for " +$ foreach ($record in $SubDomain.Group) { # Initialize $resourceAName = $record.A $PublicIP = $record.ip $resourceSubDomainName = $record.Subdomain $zoneName = $record.Domain $resourceName = $resourceAName + "." + $resourceSubDomainName + "." + $zoneName

Write-Output ("Record for $resourceName ") #Create individual DNS records here

} } [/powershell]

The array will give you the records you need to create.

All things being equal and a little bit of luck...

To access this external Azure Stack instance via Powershell you will need a few details and IDs. Most of this is easy enough, however, to get your $EnvironmentID from the deployment Host, open c:\ecetore\ and find your deployment XML. Approx 573kb. Inside this file search for 'DeploymentGuid' This is your Environment ID.  Or you can run this code on the host, you may need to change the $deploymentfile parameter

[powershell] param ( $DeploymentFile = 'C:\EceStore\403314e1-d945-9558-fad2-42ba21985248\80e0921f-56b5-17d3-29f5-cd41bf862787' )

[Xml]$DeploymentStore=Get-Content $DeploymentFile | Out-String $InfraRole=$DeploymentStore.CustomerConfiguration.Role.Roles.Role|? Id -eq Infrastructure $BareMetalInfo=$InfraRole.Roles.Role|? Id -eq BareMetal|Select -ExpandProperty PublicInfo $PublicInfoRoles=$DeploymentStore.CustomerConfiguration.Role.Roles.Role.Roles.Role|Select Id,PublicInfo|Where-Object PublicInfo -ne $null $DeploymentDeets=@{ DeploymentGuid=$BareMetalInfo.DeploymentGuid; IdentityApplications=($PublicInfoRoles.PublicInfo|? IdentityApplications -ne $null|Select -ExpandProperty IdentityApplications|Select -ExpandProperty IdentityApplication|Select Name,ResourceId); VIPs=($PublicInfoRoles.PublicInfo|? Vips -ne $null|Select -ExpandProperty Vips|Select -ExpandProperty Vip); } $DeploymentDeets.DeploymentGuid [/powershell]

Plug all the details into this connection script to access your stack instance. Well Commented code credit to Chris Speers.

[powershell] #Random Per Insall $EnvironmentID='xxxxxxxx-xxxx-4e03-aac2-6c2e2f0a517a' #The DNS Domain used for the Install $StackDomain='' #The AAD Domain Name (e.g. $AADDomainName='' #The AAD Tenant ID $AADTenantID = '' #The Username to be used $AADUserName='' #The Password to be used $AADPassword='SuperSecret!'|ConvertTo-SecureString -Force -AsPlainText #The Credential to be used. Alternatively could use Get-Credential $AADCredential=New-Object PSCredential($AADUserName,$AADPassword) #The AAD Application Resource URI $ApiAADResourceID="https://api.$StackDomain/$EnvironmentID" #The ARM Endpoint $StackARMUri="Https://api.$StackDomain/" #The Gallery Endpoint $StackGalleryUri="Https://portal.$($StackDomain):30016/" #The OAuth Redirect Uri $AadAuthUri="$AADTenantID/" #The MS Graph API Endpoint $GraphApiEndpoint="graph.$($StackDomain)"

$ResourceManager = "https://api.$($StackDomain)/$($EnvironmentID)" $Portal = "https://portal.$($StackDomain)/$($EnvironmentID)" $PublicPortal = "https://publicportal.$($StackDomain)/$($EnvironmentID)" $Policy = "https://policy.$($StackDomain)/$($EnvironmentID)" $Monitoring = "https://monitoring.$($StackDomain)/$($EnvironmentID)"

#Add the Azure Stack Environment Get-azurermenvironment -Name 'Azure Stack AS01'|Remove-AzureRmEnvironment Add-AzureRmEnvironment -Name "Azure Stack AS01" ` -ActiveDirectoryEndpoint $AadAuthUri ` -ActiveDirectoryServiceEndpointResourceId $ApiAADResourceID ` -ResourceManagerEndpoint $StackARMUri ` -GalleryEndpoint $StackGalleryUri ` -GraphEndpoint $GraphApiEndpoint

#Add the environment to the context using the credential $env = Get-azurermenvironment -Name 'Azure Stack AS01' Add-AzureRmAccount -Environment $env -Credential $AADCredential -Verbose Login-AzureRmAccount -EnvironmentName 'Azure Stack AS01'

get-azurermcontext Write-output "ResourceManager" Write-output $ResourceManager Write-output "`nPortal" Write-output $Portal Write-output "`nPublicPortal" Write-output $PublicPortal Write-output "`nPolicy" Write-output $policy Write-output "`nMonitoring " Write-output $Monitoring [/powershell]

Returning something like this.

Thanks for reading.  Hopefullly this helped you in some way.


Azure, Azure Active Directory, and PowerShell. The Hard Way


In my opinion, a fundamental shift for Windows IT professionals occurred with the release of Exchange 2007.  This established PowerShell as the tool for managing and configuring Microsoft enterprise products and systems going forward.  I seem to remember hearing a story at the time that a mandate was established for every enterprisey product going forward; each GUI action would have a corresponding PowerShell execution.  If anyone remembers the Exchange 2007 console, you could see that in action.  I won’t bother corroborating this story, because the end results are self-evident.  I can’t stress how important this was.  Engineers and administrators with development and advanced scripting skills were spared the further indignity of committing crimes against Win32 and COM+ across a hodgepodge of usually awful languages.  Windows administrators for whom automation and scripting only meant batch files, a clear path forward was presented.

PowerShell and Leaky Abstractions

For roughly two years now, the scope of my work has been mostly comprised of Azure integration and automation.  Azure proved to be no exception to the PowerShell new world order. I entered with wide-eyed optimism and I quickly discovered a great deal of things, usually of a more advanced nature, that could not be done in the portal and purportedly only via PowerShell. As I continue to receive product briefings, I have developed a bit of a pedantic pet-peeve.  PowerShell is always front and center in the presentations when referencing management, configuration, and automation.  However, I continue to see a general hand wave given as to the underlying technologies (e.g. WMI/CIM, REST API) and requirements.  I absolutely understand the intent, PowerShell has always been meant to provide a truly powerful environment in a manner that was highly accessible and friendly to the IT professional.  It has been a resounding success in that regard.  A general concern, I have, is that of too much abstraction.  There is a direct correlation between your frustration level and how far your understanding of what is going on is when an inevitable edge case is hit and the abstraction leaks.

Getting Back to the Point

All of that is a really long preface to the actual point of this post. I’ve never been a fan of the Azure Cmdlets for a number of reasons, most of which I don’t necessarily impugn the decisions made by Microsoft. To be honest, I think  both Switch-AzureMode (for those that remember) and the rapid release cadence that has introduced many understandably unavoidable breaking changes has really prejudiced me; as a result I tend to use the REST API almost exclusively. The fact is, modern systems and especially all of the micro-service architectures being touted are all powered by REST API. In the case of the Microsoft cloud, with only a few notable exceptions, authentication and authorization is handled via Azure Active Directory. It behooves the engineer or developer focused on Microsoft technologies to have a cursory understanding.  Azure Active Directory, Azure, and Office 365 are intrinsically linked. Every Azure and/or Office 365 Subscription is linked with an Azure AD tenant as the primary identity provider. The modern web seems to have adopted OAuth as an authorization standard and Azure AD can greatly streamline the authorization of web applications and API. The management and other API surfaces of Azure (and Azure Stack) and Office 365 have always taken advantage of this. The term you’ve likely heard thrown around is Bearer Token. That is more accurately described as an authorization header on the HTTP request containing a JWT (JSON Web Token).  My largest issue with the Azure and PowerShell automation has been the necessity to jump through hoops to simply obtain that token via PowerShell.  In 2016 a somewhat disingenuously Cmdlet named Get-AzureStackToken in the AzureRM.AzureStackAdmin module finally appeared.  I’m certain a large portion of the potential reading audience has used a tool like Fiddler, Postman, or even more recently to either inspect or interact with these services.  Those who have can feel free to skip the straight to where this applies to PowerShell.

There are two types of applications you can create within Azure AD, each of with are identified with a unique Client Id and valid redirect URI(s) as the most relevant properties we’ll focus on.

Web Applications

  • Web applications in Azure Active Directory are OAuth2 confidential clients and likely the most appropriate option for modern (web) use cases.

  • Tokens are obtained on behalf of a user using the OAuth2 authorization grant flow. An authorization code or id token will be supplied to the specified redirect URI.

  • If needed, client credentials (a rolling secret key) can be used to obtain tokens on behalf of the user or on it’s own from the web application itself.

Native Applications

  • Native applications in Azure Active Directory are OAuth2 public clients (e.g. an application on a desktop or mobile device).

  • These applications can obtain a token directly (with managed organizational accounts) or use the authorization grant flow, but application level permissions are not applicable.

Getting to the PowerShell

I will focus primarily on the Native application type as it is most relevant to PowerShell. Most of the content will use Cmdlets from a module that will be available with this post.   The module is heavily derived/inspired by the ADAL libraries, has no external dependencies and accept a friendly PSCredential (with the appropriate rights) for any user authentication.  The Azure Cmdlets use a Native application with a Client Id of 1950a258-227b-4e31-a9cf-717495945fc2 and a redirect URI of urn:ietf:wg:oauth:2.0:oob (the prescribed default for native applications).   We’ll use this for our first attempt at obtaining a token for use against Azure Resource Manager or the legacy Service Management API.  A peculiar detail of Azure management is that this one of the scenarios a token is fungible for disparate endpoints. I always use as my audience regardless of whether I will be working with ARM or SM.  A token obtained from that audience will work the same as one from .

If all you would like is a snippet to obtain a token using the Azure, I’ll offer you a chance to bail out now:

$Password="asecurepassword"|ConvertTo-SecureString -AsPlainText -Force
$Credential=New-Object pscredential($UserName,$Password)
Get-AzureStackToken -Resource $Resource -AadTenantId $TenantId -ClientId $PoshClientId -Credential $Credential -Authority "$TenantId"

A good deal of the functionality around provisioning applications and service principals has come to the Azure Cmdlets.  You can now create applications, service principals from the applications, and role assignments to the service principals. To create an application, in this case one that would own a subscription, you would write something like this:

$AppDisplayName='The Subscription Owning Web App'
$NewWebApp=New-AzureRmADApplication -DisplayName $AppDisplayName -HomePage $HomePage `
    -IdentifierUris $IdentifierUris -StartDate (Get-Date) -EndDate (Get-Date).AddYears(1) `
    -Password $ApplicationSecret
$WebAppServicePrincipal=New-AzureRmADServicePrincipal -ApplicationId $NewWebApp.ApplicationId
$NewRoleAssignment=New-AzureRmRoleAssignment -ObjectId $NewWebApp.Id -RoleDefinitionName 'owner' -Scope "/subscriptions/$SubscriptionId"
$ServicePrincipalCred=New-Object PScredential($NewWebApp.ApplicationId,($ApplicationSecret|ConvertTo-SecureString -AsPlainText -Force))
Add-AzureRmAccount -Credential $ServicePrincipalCred -TenantId $TenantId -ServicePrincipal

For those that stuck around, let’s take a look at obtaining JWT(s), inspecting them, and putting them to use.

I added a method for decoding the tokens, so we will have a look at the access token.  A JWT is comprised of a header, payload, and signature.  I will leave explaining the claims within the payload to identity experts.

Now that we have a token, let's use it for something useful, in this case we will ask Azure (ARM) for our associated subscriptions.

Examining the OAuth2 Flow

If you are not interested in what is going on behind the scenes feel free to skip ahead.  Each application exposes a standard set of endpoints and I will not discuss the v2.0 endpoint as I do not have enough experience using it.  There are two endpoints in particular to make note of,{tenantid}/oauth2/authorize and{tenantid}/oauth2/token, where {tenantid} represents the tenant id (guid or domain name) e.g. or common for multi-tenant applications.  Azure AD obviously supports federation and the directing traffic to the appropriate authorization endpoint is guided by a user realm detection API of various versions at  If we inspect the result for a fully managed Azure AD account we see general tenant detail.

If we take a look at a federated user we will see a little difference, the AuthURL property.

userrealm federated

This show us the location of our federated authentication endpoint. The token will actually be requested via a SAML user assertion that is received from an STS, in this case ADFS.

The OAuth specification uses the request parameter collection for token and authorization code responses. A username and password combination can be used to directly request a token in the fully managed scenario public client scenario.

A POST request can go directly to the Token endpoint with the following query parameters:


The Application Id


The Resource URI to access




The username


The password

The ADFS/WSTrust will entail sending a SOAP request to the WSTrust endpoint to authenticate and use that response to create the assertion that is exchanged for an access token.  Through user realm detection we can find the ADFS username/password endpoint.  A SOAP envelope can be sent to  endpoint to receive a security token response, containing the assertions needed.

A POST request is sent to the Username/Password endpoint for ADFS with the following envelope with noteable values encased in {}:

<s:Envelope xmlns:s=''
        <a:Action s:mustUnderstand='1'></a:Action>
        <a:messageID>urn:uuid:{Unique Identifier for the Request}</a:messageID>
        </a:ReplyTo>        <!-- The Username Password WSTrust Endpoint -->
        <a:To s:mustUnderstand='1'>{Username/Password Uri}</a:To>
        <o:Security s:mustUnderstand='1'
            xmlns:o=''>            <!-- The token length requested -->
            <u:Timestamp u:Id='_0'>
                <u:Created>{Token Start Time}</u:Created>
                <u:Expires>{Token Expiry Time}</u:Expires>
            </u:Timestamp>            <!-- The username and password used -->
            <o:UsernameToken u:Id='uuid-{Unique Identifier for the Request}'>
                <o:Username>{UserName to Authenticate}</o:Username>
                <o:Password>{Password to Authenticate}</o:Password>
        <trust:RequestSecurityToken xmlns:trust=''>
            <wsp:AppliesTo xmlns:wsp=''>

The token response is inspected for SAML assertion types (urn:oasis:names:tc:SAML:1.0:assertion or urn:oasis:names:tc:SAML:2.0:assertion) to find the matching token used for the OAuth token request.

<s:Envelope xmlns:s=""
        <a:Action s:mustUnderstand="1"></a:Action>
        <o:Security s:mustUnderstand="1"
            <u:Timestamp u:Id="_0">
        <trust:RequestSecurityTokenResponseCollection xmlns:trust="">            <!-- Our Desired Token Response -->
                    <wsu:Created xmlns:wsu="">2016-01-03T01:34:41.622Z</wsu:Created>
                    <wsu:Expires xmlns:wsu="">2016-01-03T02:34:41.622Z</wsu:Expires>
                <wsp:AppliesTo xmlns:wsp="">
                    <wsa:EndpointReference xmlns:wsa="">
                <trust:RequestedSecurityToken>                    <!-- The Assertion -->
                    <saml:Assertion MajorVersion="1" MinorVersion="1" AssertionID="_e3b09f2a-8b57-4350-b1e1-20a8f07b3d3b" Issuer="" IssueInstant="2016-08-03T01:34:41.640Z"
                        <saml:Conditions NotBefore="2016-01-03T01:34:41.622Z" NotOnOrAfter="2016-01-03T02:34:41.622Z">
                                <saml:NameIdentifier Format="urn:oasis:names:tc:SAML:1.1:nameid-format:unspecified">130WEAH65kG8zfGrZFNlBQ==</saml:NameIdentifier>
                            <saml:Attribute AttributeName="UPN" AttributeNamespace="">
                            <saml:Attribute AttributeName="ImmutableID" AttributeNamespace="">
                        <saml:AuthenticationStatement AuthenticationMethod="urn:oasis:names:tc:SAML:1.0:am:password" AuthenticationInstant="2016-08-03T01:34:41.607Z">
                                <saml:NameIdentifier Format="urn:oasis:names:tc:SAML:1.1:nameid-format:unspecified">130WEAH65kG8sfGrZENlBQ==</saml:NameIdentifier>
                        <ds:Signature xmlns:ds="">
                                <ds:CanonicalizationMethod Algorithm="" />
                                <ds:SignatureMethod Algorithm="" />
                                <ds:Reference URI="#_e3b09f2a-8b57-4350-b1e1-20a8f07b3d3b">
                                        <ds:Transform Algorithm="" />
                                        <ds:Transform Algorithm="" />
                                    <ds:DigestMethod Algorithm="" />
                            <KeyInfo xmlns="">
                    <o:SecurityTokenReference k:TokenType=""
                        <o:KeyIdentifier ValueType="">_e3b09f2a-8b57-4350-b1e1-20a8f07b3d3b</o:KeyIdentifier>
                    <o:SecurityTokenReference k:TokenType=""
                        <o:KeyIdentifier ValueType="">_e3b09f2a-8b57-4350-b1e1-20a8f07b3d3b</o:KeyIdentifier>

A POST request is sent to the Token endpoint with the following query parameters:


The Application Id


The Resource URI to access


The base64 encoded SAML token


urn:ietf:params:oauth:grant-type:saml1_1-bearer urn:ietf:params:oauth:grant-type:saml2-bearer



A GET request is sent to the Authorize endpoint with some similar query parameters:


The Application Id


The location within the application to handle the authorization code




login consent admin_consent


optional scope for access (app uri or openid scope)

The endpoint should redirect you to the appropriate login screen via user realm detection.  Once the user login is completed, the code is added to the redirect address as either query parameters (default) or a form POST.  Once the code is retrieved it can be exchanged for a token. A POST request is sent to the Token endpoint as demonstrated before with some slightly different parameters:


The Application Id


The Resource URI to access


The authorization code




previous scope


required if confidential client

Tying it All Together

To try to show some value for your reading time, lets explore how this can be used as the solutions you support and deploy become more tightly integrated with the Microsoft cloud.  We'll start by creating a new Native application in the legacy portal.


I used https://itdoesnotmatter here, but you might as well follow the guidance of using urn:ietf:wg:oauth:2.0:oob.  We will now grant permissions to Azure Active Directory and Azure Service Management (for ARM too).


I will avoid discussing configuring the application to be multi-tenant as the processes I outline are identical, it is simply a matter of the targeted tenant.  You should end up with something looking like this.


Let's now try to go get a token for our new application and put it to use.  This should look exactly the same as retrieving the previous token.

$AuthCode=Approve-AzureADApplication -ClientId $NewClientId -RedirectUri 'https://itdoesnotmatter/' -TenantId -AdminConsent


Epic failure!  Unfortunately we run into a common annoyance, the application must be consented to interactively.  I do not know of any tooling that exists to make this easy.  I added a function to make this a little easier and it supports a switch of AdminConsent to approve the application for all users within the tenant.  And step through the consent process to receive an authorization code.

$AuthCode=Approve-AzureADApplication -ClientId $NewClientId -RedirectUri 'https://itdoesnotmatter/' -TenantId -AdminConsent

Approve App

Once the authorization code is obtained it can be exchanged for a token, for which I provided another function.  That token can now be used in the exact same manner as the Azure Cmdlet application.

$TokenResult=Get-AzureADAccessTokenFromCode '' -ClientId $NewClientId -RedirectUri 'https://itdoesnotmatter/' -TenantId -AuthorizationCode $AuthCode


If you wanted to handle some Azure Active Directory objects, we can target a different audience, and execute actions appropriate to the account's privilege level.   In the following example we will create a new user.

$GraphUriBuilder=New-Object System.UriBuilder($GraphBaseUri)
    "accountEnabled": true,
    "displayName": "Johnny Law",
    "mailNickName" : "thelaw",
    "passwordProfile": {
        "password": "Password1234!",
        "forceChangePasswordNextLogin": false
    "userPrincipalName": "$TenantId"
$AuthResult=Get-AzureADUserToken -Resource $GraphBaseUri -ClientId $NewClientId -Credential $Credential -TenantId $TenantId
$AuthHeaders=@{Authorization="Bearer $($AuthResult.access_token)"}
$NewUser=Invoke-RestMethod -Uri $GraphUriBuilder.Uri -Method Post -Headers $AuthHeaders -Body $NewUserJSON -ContentType "application/json"

If we want to continue the “fun” with Office 365 we can apply the exact sample approach with the Office 365 Sharepoint Online application permissions.  In the interest of moving along and with no regard for constraining access, we will configure the permissions in the following manner.


We’ll now do some querying of the Office 365 SharePoint video API with some more script.

$SpUriBuilder=New-Object System.UriBuilder($SharepointUri)
$AuthResult=Get-AzureADUserToken -Resource $SharepointUri -ClientId $NewClientId -Credential $Credential
$Headers=@{Authorization="Bearer $($AuthResult.access_token)";Accept="application/json";}
$VideoDisco=Invoke-RestMethod -Uri $SpUriBuilder.Uri -Headers $Headers $VideoDisco|Format-List
$ChannelUrlBuilder=New-Object System.UriBuilder($VideoPortalUrl)
$ChannelOData=Invoke-RestMethod -Uri $ChannelUrlBuilder.Uri -Headers $Headers
foreach ($Channel in $ChannelOData.Value)
    $VideoUriBuilder=New-Object System.UriBuilder($Channel.'')
    Invoke-RestMethod -Uri $VideoUriBuilder.Uri -Headers $Headers|Select-Object -ExpandProperty value

We should see some output that looks like this:


I’ve had Enough! Please Just Show me the Code.

For those who have endured or even skipped straight here, I present the following module for any use your dare apply.  The standard liability waiver applies and it is presented primarily for educational purposes.  It came from a need to access the assortment of Microsoft cloud API in environments where we could not always ensure the plethora of correct Cmdlets are installed.  Initially, being a .Net guy, I just wrapped standard use cases around ADAL .Net.  I really wanted to make sure that I really understood OAuth and OpenId Connect authorization flows as is relates to Azure Active Directory.  The entire theme of this lengthy tome is to emphasize the importance of having a relatively advanced understanding of these concepts.  Regardless of your milieu, if it has a significant Microsoft component, the demand to both integrate and support the integration(s) of numerous offerings will only grow larger.  The module is primarily targeted at the Native Client application type, however there is support for the client secret and implicit authorization flows.  There are also a few utility methods that are exposed as they may have some diagnostic use or otherwise.  The module exposes the following methods all of which support Get-Help:

  • Approve-AzureADApplication

    • Approves an Azure AD Application Interactively and returns the Authorization Code

    • ConvertFrom-EncodedJWT

      • Converts an encoded JWT to an object representation

      • Get-AzureADAccessTokenFromCode

        • Retrieves an access token from a consent authorization code

        • Get-AzureADClientToken

          • Retrieves an access token as a an OAuth confidential client

          • Get-AzureADUserToken

            • Retrieves an access token as a an OAuth public client

            • Get-AzureADImplicitFlowToken

              • Retrieves an access token interactively for a web application with OAuth implicit flow enabled

              • Get-AzureADOpenIdConfiguration

                • Retrieves the OpenId connect configuration for the specified application

                • Get-AzureADUserRealm

                  • Retrieves a the aggregate user realm data for the specified user principal name(s

                  • Get-WSTrustUserRealmDetails

                    • Retrieves the WSFederation details for a given user prinicpal name

Get it here: Azure AD Module

I hope you find it useful and remember not to fear doing things the hard way every so often.
